Paddle Wheel Aerator

The Paddle Wheel Aerator include Two-Impeller Paddle Wheel Aerator, Four-Impeller Paddle Wheel Aerator, Six-Impeller Paddle Wheel Aerator, Eight-Impeller Paddle Wheel Aerator, Ten-Impeller Paddle Wheel Aerator, and Twelve-Impeller Paddle Wheel Aerator. The primary working principle of The Paddle Wheel Aerator is to use the motor as the power, decelerate through the reducer, and drive the impeller to rotate. The Paddle Wheel Aerator can make the water in the water rotate and become a dynamic state, enabling dissolved water to evenly distributed in all directions (horizontally and vertically) of the water body, which greatly enhances the oxygen content of the fish pond and provides effective conditions for the high-density breeding of farmers. In the meanwhile, The Paddle Wheel Aerator produced by Jinhulong Company make significant effect on sewage discharging at the bottom of the high-level pond，reducing diseases and promoting the growth of fish and shrimp.

Model

 Power Voltage
V/50Hz		  Power efficiency
 (kg/kW.h)		 DO
(kg/hr)		 AMP
 (A)		  Weight
(kg）		 40 Container
set
kW Hp
YC-0.30（Small 2-leaf）
Effectve water flow:30m		 0.3 0.5 220-380 ≥1.0 ≥1.0 0.60 37 ≈300
YC-0.75 （2-leaf）
Effectve waterfiow:50m		 0.75 1 220 ≥1.25 ≥1.6 1.25 80 185
YC-0.75（2-leaf）
Effective waterfiow:50m		 0.75 1 380 ≥1.25 ≥1.9 1.25 80 185
YC-0.75（4-leaf）
Efective water fiow:50m		 0.75 1 380 ≥1.25 2.3-2.6 1.60 80 185
YC-1.5 （4-leaf）
Effective water fiow:55m		 1.5 2 220 ≥1.25 2.6-2.9 2.45 100 133
YC-1.5 （4-leaf）
Effective water fiow:55m		 1.5 2 380 ≥1.25 2.8-3.1 2.45 100 133
YC-1.5 （6-leaf）
Effective water fiow:60m		 1.5 3 380 ≥1.5 3.6-3.8 2.60 120 66
YC-2.2（8~10-leaf）
Effective waterflow:65m 		 2.2 3 380 ≥1.5 4.0-4.3 2.80 125 63
YC-2.2（12-leaf）
Effective water flow:70r		 3 3.5 380 ≥1.5 4.3-4.6 3.0 135 60
YC-3.0（14-leaf）
Effective water flow:75m		 3 4 380 ≥1.65 4.7-5.1 5.3 187 57
YC-3.0（16-leaf）
Effective water flow:80m		 3 4 380 ≥1.65 5.3-5.6 5.3 192 54



About Us

Taizhou Jinhu Mechanical & Electrical Co.LTD is a modern high-tech enterprise specializing in manufacturing vacuum pumps and fishery machinery. We are committed to providing high-quality vacuum and fishery solutions for global customers. The company is located in Taizhou, Zhejiang, the cradle of private enterprises in China. The company cover an area of 30,000 square meters and own over 100 sets of advanced processing machines, mainly from Japan and Germany. We have the capacity of producing over 200,000 sets of machines every year. As a professional manufacturer in this industry, we have the integrated ability of technical R&D, manufacturing and sales. We have got the certification of ISO9001:2015, with many products awarded CE certification, utility model design and patent for invention. We are admitted into the list of enterprises enjoying national promotion and national subsidies in 2010, and also have the self-supported import & export rights. The Jinhulong series of products sells well around China, and are also exported to East-south Asia, Middle East, Europe and other regions, enjoying a good reputation and fame among our clients.

We provide products of reliable quality on the basis of demanding product design, reasonable processing flow and strict examination. As we have the advanced technologies in aspects like mechanical processing, major parts and components are finished in the factory to ensure full implementation of specific quality managements. In addition, as our company is located in the largest market of raw material, accessories and equipment in East Zhejiang province, we enjoy lower cost in raw materials. All in all, our cost advantage and processing power ensure that we can deliver   competitiveness to clients.

The people of Jinhulong will be devoted to supplying agricultural and aquacultural machines featured by higher quality, higher efficiency and being more energy-saving and environmental-friendly. We will build up a global brand and improve the development level of Chinese agricultural and aquaculture equipment, thus making a contribution to the world.

Honor

  • Production of Oxygen Aerator
  • Quality management system certification
  • National industrial products production license
  • ESO
  • ESO
  • Contract-observing and trustworthy unit
  • Certificate of Registration
  • Agricultural machinery promotion identification certificate
  • Agricultural machinery promotion identification certificate
  • Agricultural machinery promotion identification certificate
  • Agricultural machinery promotion identification certificate
  • Agricultural machinery promotion identification certificate

News

Contact us now

Paddle Wheel Aerator

Main Feature:
Various impeller options:
The versatility of the Regular Series lies in its various impeller configurations (from two to twelve), allowing farmers to select the ideal model based on the size and requirements of their aquatic system. This adaptability ensures efficient aeration in aquaculture operations of different sizes.
Motor drive power:
At the heart of a waterwheel aerator is the rugged motor, which is the power source for the entire system. The energy of the motor is harnessed and transmitted through a precision-designed reducer, allowing controlled deceleration to optimally drive the impeller to rotate.
Enhanced Oxygen Content:
Impeller aerator can effectively disperse dissolved oxygen. By creating a higher-oxygen environment, aerators create optimal conditions for aquatic life to grow and survive, especially in densely populated areas.
High-density breeding support:
Farmers engaged in high-intensity agriculture find a reliable ally in the paddlewheel aerator. Enhanced oxygenation and water circulation help create an environment conducive to fish and shrimp thriving, allowing farmers to maximize yields without compromising the health of aquatic populations.
Effective discharge volume of sewage:
In addition to oxygenation, the impeller aerator produced by Jinhulong Company has also achieved good results in sewage discharge. Aerators are particularly useful in elevated ponds, helping to remove waste and contaminants from the pond bottom, reducing the risk of disease and maintaining water quality.
Reduce disease:
The conventional series demonstrates a tangible impact on disease reduction within aquaculture systems. Aerators promote a healthier pond environment through effective oxygenation and waste removal as a preventive measure against diseases that can adversely affect fish and shrimp populations.
Promote growth:
A paddle wheel aerator does more than just aerate; it actively promotes fish and shrimp growth. The optimal conditions created by aerators contribute to the overall well-being of aquatic life, promoting accelerated growth and ensuring a robust and productive aquaculture system.
In short, Jinhulong's paddle wheel aerator (conventional) solves key aspects such as oxygenation, water circulation, sewage management, disease prevention and growth promotion. This aerator is available in a variety of models to meet various requirements. It is an indispensable tool for modern fish and shrimp farming, creating a new era of efficient and sustainable aquaculture.
